Advertiser Web Integration

Please Note: This documentation references invoca.net in the Web Integration examples below. However, previous installations referencing ringrevenue.com are still valid. Advertiser Web Integration is a platform feature that uses JavaScript to switch the advertiser’s phone number with a campaign’s tracking phone number (promo number). When the advertiser and their marketing partners send online traffic to the advertiser’s landing page, their tracking phone number appears on the page and attributes the marketing source for any resulting phone calls. Campaign promo numbers can be static or they can be dynamically generated using the RingPool API feature.

Installation Instructions

From the Advertiser Home Page, choose Tools gear, Web Integration.

In the Web Integration, Settings tab, enter the phone number to replace on your website.

Click Update.
Click “Get Code” tab to access your custom generated web integration code.
Place the web integration code on your website (every page where you want to display the promo number) in the footer just above the </body> tag. This step only has to be done once.

Testing the code

To test web integration inside the platform, from the Web Integration panel, click Integration Test. Select “Open Test”.

Click “Start Test”. If the test is successful, the results return a green checkmark.

If the test is unsuccessful, the results return with a red exclamation. The web integration code is not installed properly or the landing page cannot be found. See Web Integration Troubleshooting below.

To test web integration outside the platform, in a browser enter the landing page URL, or other web integrated page’s URL, and append PPCPN=9999999999. If the URL has a query string, use an “&” to append the PPCPN, for example: http://www.invoca.com/corporate/landhere/?r=1&PPCPN=9999999999 If the URL does not have a query string, use a “?” to append the PPCPN, for example: http://www.invoca.com?PPCPN=9999999999 If the test is successful, the number or numbers on the page change to 999-999-9999. If test is unsuccessful, the number or numbers do not change to 999-999-9999. See Web Integration Troubleshooting below.

Web Integration Troubleshooting

Check that the phone number is entered in the Web Integration, Settings tab and matches the phone number on your website.
If you display other phone numbers in addition to the number entered in Web Integration, Settings tab, make sure you are using additional client side Web Integration settings to accommodate multiple phone numbers. See below for examples.
Check for syntax errors on the page, for example, missing commas or brackets.

Web Integration Settings

Web Integration settings can be set on the server or the client side (browser side). As an example, the NumberToReplace field can be set on the platform(server side) and in the JavaScript function(client side). A large majority of advertisers only need to configure the settings on the platform or server side. Including Web Integration settings on the client side should only be done if the Web Integration’s behavior needs to be customized. The client side settings always takes precedence over the server side.

Server Side Integration

All of the server side settings are defined in the Web Integration, Settings tab.

Click on “Advanced Tracking Settings” to view and configure advanced settings.

Advertisers can have campaign traffic and general traffic going to the same integrated landing pages. The Web Integration code distinguishes between the two types of traffic and behaves accordingly. Campaign traffic arrives on the landing page by clicking on a link supplied by the Invoca platform. The link loads the promo number dynamically with the web integration code. General traffic arrives on the landing page without clicking on an Invoca platform link. To track and report on all general traffic, select “Track all calls”. Select the Campaign to track general traffic. Select or create the RingPool to use for general traffic and click Update.

Client Side Integration & Parameters

The client side settings are listed in the table below. Most installations do not require any client side changes. To initialize the Web Integration code, pass the integration settings in a hash to the Invoca.advertiser_integration function.

Invoca.advertiser_integration = {
  id : 'YOUR_ID_HERE'
};

Required parameters:
id	String	Unique Advertiser ID. (Auto Populated in Tools, Web Integration, Get Code tab)

Optional parameters:
numberToReplace	String	Default: `‘’` Note: This field can be specified on the server side on the Web Integration, Settings tab. It is recommended to use this and not add this parameter to the Javascript. The phone number on the page to replace with an Invoca promo number. Prefix international numbers with ‘+’ and separate the country code with a space. Other punctuation is ignored but can be used for readability. The number is replaced in the same format as is used on the page. Example values: ‘805-555-5784’, ‘+1 8055555784’, ‘020 8905 1456’, or ‘+44 020 8905 1456’
numberSelector	String	Default: `‘’` The selector of the HTML elements where you want phone number inserted. Prefix IDs with ‘#’ and classes with ‘.’ For example, ‘.promoNumber’ replaces the number in all HTML elements having class=”promoNumber”.
campaignId	String	Default: `null` Note: This option can be specified on the server side on the Web Integration, Settings tab (default campaign for general site traffic). It is recommended to use the server side settings and not add this parameter to the Javascript. Unique campaign ID. If you need separate settings per landing page, then this field is required.
ringPoolId	String	Default: `null` Note: This can be specified on the server side on the Web Integration, Settings tab (default RingPool for general site traffic). It is recommended to use the server side settings and not add this parameter to the Javascript. Unique RingPool ID. If you need separate settings per landing page, then this field is required. For general traffic coming to the site, the RingPool specified in Advanced Tracking Settings is used to allocate a number. If the RingPool is not specified, the campaign ID is used to find a valid RingPool.
numberSeparator	String	Default: `‘-’` Character to separate phone digit groups.
numberLeadingOne	Boolean	Default: `true`. If true, inserts a leading ‘1’ then the separator in front of the number.
showSelector	String	Default: `‘’` The selector of the HTML elements you want to set to visible (using jQuery.show) when a promo number is swapped out. Prefix IDs with ‘#’ and classes with ‘.’ . This is useful for having a span that says “call now:” which should only be displayed if a valid phone number is inserted. See also hideSelector. (The elements are not shown if Click to Call is being used and ctcUseButton is set to true.)
hideSelector	String	Default: `‘’` The selector of the HTML elements you want to have set to display:none (removed from the page visually). Prefix IDs with ‘#’ and classes with ‘.’ This is useful for hiding the image that has the default company phone number embedded in it, when a valid promo number is found. See also showSelector and notVisibleSelector.
notVisibleSelector	String	Default: `‘’` The selector of the HTML elements you want to have set to visibility:hidden (hide on page in place). Prefix IDs with ‘#’ and classes with ‘.’ This is useful for hiding an element when a valid promo number is found but keeping the page layout the same. See also hideSelector and showSelector.
onLoadWithNumber	Function	Default: `null` A callback function called after web integration has run and modified the DOM using the selectors specified in the parameters. Called with the following arguments: is_ctc boolean - true if CTC is enabled phone_number string - formatted phone number (empty if CTC is enabled and a promo number is not available).
onLoadNoNumber	Function	Default: `null` A callback function called after Web Integration runs and no modification is made.
mobileClickToCall	Boolean	Default: `true` When true, automatically wraps valid promo numbers in tel links when viewed on a mobile browser, so they are clickable and launch a dialer. Non-mobile browsers will get the default behavior of just a phone number. If your site already has dynamic behavior specified on the phone number DOM element, you may want to set this to false to prevent conflicts.
networkParamName	String	Default: `‘sid’` The query parameter name used for passing promo numbers through click-tracking URLs. (Configured within your main network, if available)
ctcUseButton	Boolean	Default: `true` Applicable when web integration is set to use the online click-to-call form. When true, modifies the elements specified by numberSelector to contain a “Call Me!” button (or ctcButtonContent if set), otherwise inserts the phone number (when available) and wires up a click handler on the element. A class of click_to_call_button is added to the element specified by numberSelector. You can add CSS styling to that class to customize the look to match your website.
ctcButtonContent	String	Default: `‘<button type=”button”>Call Now!</button>’` Applicable when Web Integration is using the online click-to-call form. HTML content to override the default online CTC call to action (button or hyperlink is recommended).
debug	Boolean	Default: `false` When true, debug information is printed to the console in browsers that support console.log() and console.error() Safari & Chrome using the Developer JavaScript Console Firefox with Firebug enabled IE8+ with Developer Tools enabled

Client Settings (Advanced)

numberToReplace vs. numberSelector There are two ways for the Web Integration code to know where to insert a tracking phone number. Note that you should only use one or the other, not both.

The numberToReplace option, which is the easy to use option, looks for the advertiser’s phone number on the web page and replaces it with the affiliate or publisher tracking phone number(promo number).
The numberSelector option, which is the robust option used for customizing the Web Integration’s behavior, looks for an HTML element that has the same ID or class name and replaces the entire element with the affiliate or publisher tracking phone number(promo number) or a click-to-call button. Click-to-call only works with this option.

Selector information

All “selector” parameters are a comma separated list of IDs or classes, where IDs are prefixed with a “#” and classes are prefixed with a “.” (similar to referencing a class or ID using jQuery or prototype). Only a single class or single ID per selector is supported, no other jQuery selector syntax is supported.

Valid: A single class: .promoNumber A single ID: #number A list of classes: .promoNumber, .mainNumber
Not valid: table > .promoNumber .promoNumber:first span#number

Simple Examples

Default example of replacing multiple phone numbers on a page, with no additional options specified: ( ‘YOUR_ID_HERE’ represents where the unique advertiser ID is inserted.)

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page</title>
  </head>

  <body>
    Call Now! 1-800-555-1234

    <div class="content">
      Here is the content of your website.
    </div>

    <div class="footer">
      Contact us: 1-800-555-1234
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id : 'YOUR_ID_HERE'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

Example with NumberToReplace options specified on the client side, replacing multiple phone numbers on a page:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page</title>
  </head>

  <body>
    Call Now! 1-800-555-1234

    <div class="content">
      Here is the content of your website.
    </div>

    <div class="footer">
      Contact us: 1-800-555-1234
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id : 'YOUR_ID_HERE',
          numberToReplace : '1-800-555-1234'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

Advanced Examples

Example changing the phone number presentation using the NumberSelector option on the client side:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page</title>
  </head>

  <body>
    Sales:<br />
    <strong><span id="site_phone_number">800.555.1234</span></strong>

    <div class="content">
      Here is the content of your website.
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
          Invoca.advertiser_integration = {
            id : 'YOUR_ID_HERE',
            numberSelector : '#site_phone_number',
            numberLeadingOne : false,
            numberSeparator : '.'
          };
      } catch( e ){ }
    </script>
  </body>
</html>

Example website that has the default phone number embedded in an image:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page with Phone Number in Image</title>
  </head>

  <body>
    <div class="header">
      <img src="http://support.invoca.net/sites/default/files/admin/company_logo.gif" />
      <img src="http://support.invoca.net/sites/default/files/admin/header_phone_number.gif" id="header_phone" />
      <span class="promoNumber"></span>
    </div>

    <div class="content">
      Here is the content of your website.
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id             : 'YOUR_ID_HERE',
          numberSelector : '.promoNumber',
          hideSelector   : '#header_phone'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

Example website that has no default phone number, and wants to show a call to action when a promo number is used:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page with No Default Phone Number</title>
  </head>

  <body>
    <div class="header">
      <img src="http://support.invoca.net/sites/default/files/admin/company_logo.gif" />
      <span class="promoCallNow" style="display: none">Call now: </span>
      <span class="promoNumber"></span>
    </div>

    <div class="content">
      Here is the content of your website.
    </div>
<!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id : 'YOUR_ID_HERE',
          numberSelector : '.promoNumber',
          showSelector   : '.promoCallNow'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

* For sites with dynamic numbers through a third party, the Invoca code can still swap promo numbers over the third party numbers by placing the span tags around the code: <span class=”promoNumber”>INSERT THIRD PARTY CODE HERE</span> Example using callbacks for custom behavior. (Note that adding tel links to numbers now happens automatically, so using a callback is no longer necessary!)

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page with Callback Functions</title>
    <script type="text/javascript">
      function showNumber( is_ctc, phoneNumber )
      {
        alert( 'The following number was returned and displayed: ' + phoneNumber + '. CTC enabled: ' + is_ctc );
      }

      function hideNumber( )
      {
        alert( 'No number was returned' );
      }
    </script>
  </head>

  <body>
    <div class="header">
      Call <span id="number" class="promoNumber">1-800-555-1234</span>
    </div>

    <div class="content">
      Here is the content of your website.
    </div>

    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id               : 'YOUR_ID_HERE',
          numberSelector   : '.promoNumber',
          onLoadWithNumber : showNumber,
          onLoadNoNumber   : hideNumber
        };
      } catch( e ){ }
    </script>
  </body>
</html>

Capturing Additional Parameters with JavaScript

You can capture additional RingPool parameters through client-side JavaScript using the poolParams option. In the following example, the visitor’s landing page timestamp is set to the poolParam “landingTime”.

<script src="//js14.invoca.net/14/integration.js"></script>
<script type="text/javascript">
  var d = new Date();
  var timeStamp = d.toUTCString();

  Invoca.advertiser_integration = {
    id : 'YOUR_ID_HERE',
        campaignId : YOUR_CAMPAIGN_ID,
        ringPoolId : YOUR_RINGPOOL_ID,
        poolParams : { landingTime : timeStamp }
    };
</script>

Displaying Different Numbers on Other Pages

Typically a visitor is “cookied” at a domain level and therefore is served the same number as they visit various web-integrated pages on the same domain. Use the “cookieId” option to set a unique cookie on different pages of a website. This allows different numbers to be served to the same visitor, depending on the page they visit. This example demonstrates how to allocate a unique number for the same user on two different pages. Any page that uses cookieId: “A” displays one number, and any page that uses cookieId: “B” displays another. Note: The cookie names (e.g. A, B) can be a custom name of your choosing.

<!-- Page 1: Cookie "A" -->
<script src="//js14.invoca.net/14/integration.js"></script>
<script type="text/javascript">
  Invoca.advertiser_integration = {
     id : 'YOUR_ID_HERE',
        campaignId : YOUR_CAMPAIGN_ID,
        ringPoolId : YOUR_RINGPOOL_ID,
        cookieId: 'A'
    };
</script>

<!-- Page 1: Cookie "B" -->
<script src="//js14.invoca.net/14/integration.js"></script>
<script type="text/javascript">
  Invoca.advertiser_integration = {
    id : 'YOUR_ID_HERE',
    campaignId : YOUR_CAMPAIGN_ID,
    ringPoolId : YOUR_RINGPOOL_ID,
    cookieId: 'B'
  };
</script>

Online Click-To-Call (CTC) Form Settings

When online CTC is enabled, the default behavior is for the phone number on the page to be replaced by a “Call now” button. When clicked, a lightbox window pops up over the page prompting the user to enter their phone number. The logo shown in the lightbox can be customized in the platform on the Customize Online Click-to-Call Form page accessed from Tools, Web Integration, Settings tab, Advanced Tracking Settings link. Example of customizing the “Call now” button when using online CTC.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page with Customized CTC Button</title>
  </head>

  <body>
    <div class="header">
      <span class="promoNumber">1-800-555-1234</span>
    </div>

    <div class="content">
      Here is the content of your website.
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id               : 'YOUR_ID_HERE',
          numberSelector   : '.promoNumber',
          ctcUseButton     : true,
          ctcButtonContent : '<a href="#">Click Here to Call</a>'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

That example results in a “Click Here to Call” link in the header, and when clicked would show the online CTC form. Example of Multiple RingPools™ on a Single Landing Page It is possible to have a single landing page with one installation of the web integration code that chooses different RingPools based on the criteria of your choosing (a query param or referring site, etc.).

On the server, you can have a list of RingPool / Campaign ID pairs, and associate each pair with a key. In the example below, the key is the referring page’s domain.
Find the correct ID pairs for a given request, and make them available for the view template.
Insert the ID pair into the web integration code using the template.

The following is an example using Ruby on Rails as the web technology. Regardless of how you are generating the landing pages, the concepts are the same. Server code (controller/action):

class LandingPageController < ApplicationController
  RING_POOL_BY_REFERRER = { "google"   : [ 7, 8  ],
                            "facebook" : [ 7, 10 ],
                            "bing"     : [ 8, 31 ] }
  def show
    @page = LandingPage.find( params[:id] )
    ids = RING_POOL_BY_REFERRER[ domain_name_from_referrer( request.env["HTTP_REFERER"] ) ]
    @campaign_id  = ids[0]
    @ring_pool_id = ids[1]
  end

  private

  \# parses string and returns "google", "facebook", etc
  def domain_name_from_referrer( referrer )
    ...
  end
end

HTML page (template):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN"
                      "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
  <head>
    <title>Landing Page with Multiple RingPools</title>
  </head>

  <body>
    <div class="header">
      <span class="promoNumber"></span>
    </div>

    <div class="content">
      <%= @page.body %>
    </div>
    <!-- Omit http from path to ensure protocol is same as current request -->
    <script src="//js14.invoca.net/14/integration.js"></script>
    <script type="text/javascript">
      try {
        Invoca.advertiser_integration = {
          id               : 'YOUR_ID_HERE',
          numberSelector   : '.promoNumber',
          campaignId       : '<%= @campaign_id %>',
          ringPoolId       : '<%= @ring_pool_id %>'
        };
      } catch( e ){ }
    </script>
  </body>
</html>

Notice that there is only ever one installation of the Web Integration code, and the only thing that needs to be set up on the server side are the IDs of the RingPool and Campaign.

Elegantly Swap Phone Number with jQuery

By default, the Advertiser Web Integration code swaps a static phone number with a campaign number when a landing page loads. Occasionally, visitors may notice that the number changes. The following example shows how to hide the static number on a landing page, and only show the Promo Number after the code runs. Additionally, in the event that no promo number is available, the code displays the original static number. Directions: Update var PHONE_SELECTOR to be the selector wrapping the phone number to be replaced. Update var FADE_SPEED to be the length of the fade in milliseconds. In the HTML, wrap your phone numbers in a span tag with the class “phone-number”. <span class=”phone-number”>STATIC NUMBER HERE</span>.

<!-- Omit http from path to ensure protocol is same as current request -->
<script src="//js11.invoca.net/11/integration.js"></script>
<script type="text/javascript">

/* -- Invoca Custom Code -- */

  // Fade in tracking number on success, or original number on fail
  function showNumber()
  {
    jQuery(PHONE_SELECTOR).fadeIn(FADE_SPEED);
  }

  // Settings
  var PHONE_SELECTOR = '.example';
  var FADE_SPEED     = 250; // Miliseconds

  // Hide default number
  jQuery(PHONE_SELECTOR).css({'display':'none'});

  // Our number swapping code
  Invoca.advertiser_integration = {
    id               : 'YOUR_ID_HERE',
    numberSelector   : PHONE_SELECTOR,
    onLoadWithNumber : showNumber,
    onLoadNoNumber   : showNumber
  };

/* -- End of Invoca Custom Code -- */

</script>
<!-- End Call Tracking Code -->

Developers Note

While testing the Web Integration code, especially advanced cases including RingPool or Campaign IDs, it is recommended that you set “debug: true”. If a RingPool ID is specified but is invalid, an error message is logged to the browser’s JavaScript console stating that the RingPool ID is invalid (note that a working phone number may still be returned, it just will not be for the correct RingPool). If both RingPool and Campaign ID are invalid, an error message is logged stating the Campaign ID is invalid.

​Installation Instructions

​Testing the code

​Web Integration Troubleshooting

​Web Integration Settings

​Server Side Integration

​Client Side Integration & Parameters

​Client Settings (Advanced)

​Selector information

​Simple Examples

​Advanced Examples

​Capturing Additional Parameters with JavaScript

​Displaying Different Numbers on Other Pages

​Online Click-To-Call (CTC) Form Settings

​Elegantly Swap Phone Number with jQuery

​Developers Note
